Сабвуфер DLS NORDICA10i

Woofer size    10" (25 cm)
Impedance    4 ohm
Recommended amplifier    300 - 600 Watt RMS
Max power handling capacity    600 W RMS
Peak power    1000 W
Frequency range    25-2500 Hz
Sensitivity    87 dB (1W/1m)
Magnet size    144 mm (5,7")
Outer diameter of woofer    266 mm (10,47")
Mounting depth    140 mm ( 5,5")
Mounting hole    236 mm (9,29")
X-max    +- 11,5 mm (0,45")
Weight    6,7 kg (14,8 lb)
T/S parameters
single V/C
Fs     33,7     Hz      Re     3,2     Ohm      Qms     9,2
Vas     22,4     liter      Vas     0,79     Cuft      Qes     0,65
Qts     0,61          Sd     314     cm²      BL     12
